Front view of the lamp face showing the lens and central light source, with the housing and bezel clearly visible.
Front view of the lamp face showing the lens and central light source, with the housing and bezel clearly visible. Angled view of the lamp face highlighting the depth of the housing and the contours of the lens and outer casing Front view of the lamp face showing the lens and central light source, with the housing and bezel clearly visible. Front view of the lamp face showing the lens and central light source, with the housing and bezel clearly visible. Front view of the lamp face showing the lens and central light source, with the housing and bezel clearly visible. Front view of the lamp face showing the lens and central light source, with the housing and bezel clearly visible. Angled view of the rear side of the lamp showing heat sink fins, mounting points, and wiring ports. Labeled diagram of the lamp detailing its key features, including lens, housing, heat sink, mounting bracket, and power connector. Technical drawing of the lamp showing precise measurements of height, width, depth, and mounting hole positions. Photometric chart displaying the light intensity distribution of the lamp in candela, with beam angles and lux levels at various distances. Photometric chart displaying the light intensity distribution of the lamp in candela, with beam angles and lux levels at various distances. Photo showing the lamp installed in a typical setting, demonstrating its placement, angle, and lighting effect in real-world use. Photo showing the lamp installed in a typical setting, demonstrating its placement, angle, and lighting effect in real-world use. Photo showing the lamp installed in a typical setting, demonstrating its placement, angle, and lighting effect in real-world use.

Utility-50

Product Code
#00U50

From £156.00

To £3,564.00

1. Utility-50 LED Work Light *
Utility-50

In stock

Find a Stockist

£156.00

PAYMENT & DELIVERY
Orders will be shipped within 1 working day (stock permitting). UK customers will be given the option for Standard or Express delivery service. International orders will dispatch via Express Courier Service, on a DAP (Delivered At Place) basis, meaning you will be liable for country specific VAT and import dutiesMore Information.

Matching form and function, the Utility-50 is a medium duty LED work light packed with performance, style, robustness, and functionality. At its core, 4x high power, premium-bin 13W LEDs deliver high levels of illumination befitting a vast array of applications and vehicles and machine types. The carefully selected 5000K colour temperature helps define the light output which is both powerful, comfortable to use over prolonged periods, and proven to optimise sharpness and definition between shapes and colours thanks to its high CRI (colour rendering index).

The Utility-50 is able to deliver more than just a high-performance work light. A version of the Utility-50 is available with integrated red tail-light function. Approved to UNECE Reg 148-R1, the red tail-light is characterised by 4 outline markers in each corner of the lamp, creating a unique and stylish appearance, over and above its safety benefits.

With its front-on dimensions shared with the Utility-80 HD, 107mm (h) x 107mm (w), this gives an indication of the lamp’s lighting competency, while the reduced depth of the lamp facilitates installation. That reduction in overall size isn’t to the detriment of performance however with the lamp carefully designed and engineered in-house, in the UK, to optimise light output considering thermal conductivity, crucial to preserving the lamps longevity and trouble-free use over many years. The strength and reliability of the Utility-50 is furthered by additional design features and build quality an upshot of our UK production, including: unbreakable polycarbonate lens with hardcoat, EMC protection - CISPR:25 (Class 3 or 5 available), automotive grade corrosion resistance a result of our in-house pre-treatment and powder coat facility, and IP68 and IP69K approval. All this backed up by our comprehensive 5-year warranty (2 years for non-automotive / industrial applications).

Depending on the model selected the Utility-50 comes supplied with male/female Deutsch connectors. The Utility-50 also comes supplied with a satin black painted stainless-steel mounting system, with either loose M10 bolts and fasteners, or fixed M10 bolt and fasteners, the latter providing for simplified installation in some instances.

Reg10 UNECE approved work light

Optional red tail-light function available (UNECE Reg 148-R1)

Optional Beacon function available -UNECE Reg 65 (XA1) approved

5000k colour temperature

CAE optimised cooling system with Electronic Thermal Management

Vacuum-metallised optics for superior light utilisation

Supplied with versatile stainless steel mounting bracket and fasteners

Fixed bolt ‘fast-mount’ solution available

‘Unbreakable’ polycarbonate lens with hardcoat

Automotive grade corrosion resistance

EMC protected- CISPR:25 (Class 3 or Class 5)

IP68 / IP69k approved

Over voltage protected

Reverse polarity protected

Includes male/female Deutsch connectors

Comprehensive range of lens covers available

5year warranty (2year for non-automotive / industrial applications)

Made in the UK

1x Utility-50 LED Work Light


Voltage Range (DC) 10-32V
LED Life 50,000 hours
Weight 0.65 kg

HIGH BEAM FUNCTION
Total Luminous Flux 5,000 Lm
Effective Lumens † 4,380 Lm
Colour Temperature 5000K
Power Consumption 50 Watts
Peak Current Draw 7.25 Amps
Current Draw (14.4V) 3.6 Amps
Connector 2-Pin/4-Pin Deutsch DT (+28cm Cable)

DIMENSIONS
Width 104 mm
Depth 58 mm
Height 104 mm

CERTIFICATION
IP Rating # IP68
Red Tail Light ECE R148 (R1)
Beacon Function ECE R65 (XA1)
EMC Certification ECE R10
EMC Protection CISPR-25 (Class 3/5)
Salt Spray Test ISO 9227
Dump Load Protection ISO 7637-2

OPERATING CONDITIONS
Operating Temperature -40oC … +90oC
Vibration (BS EN 60068) 10Hz > 1000Hz, 0.14>20 (m/s²)²/Hz

PHOTOMETRIC DATA
Horizontal / Vertical Beam Angle 80° / 80°
1 Lux 71m
5 Lux 32m
20 Lux 16m
50 Lux * 10m




† - Effective lumens takes into consideration the amount of light in a 'field-of-view' defined as an area +/- 90o left/right, and +/- 90o up/down.

* - 50 Lux represents HSE guidelines for effective illumination when working outdoors at night.

# - All Lazer products are designed to meet the requirements of IP68 testing. Every lamp produced at our UK facility is fully submerged under water prior to sending out.

  • Utility-50 LED Work Light
  • Mounting Bracket (attached to lamp)
  • Installation Instructions
